15W TRIAC DIM DRIVER PUCK LT - 12V DC 108-132VAC DIMMABLE - PLT-12619

SKU:
PLT-12619
15W TRIAC DIM DRIVER PUCK LT - 12V DC 108-132VAC DIMMABLE - PLT-12619
  • A complete puck light system requires the fixture(s), one hub (PLT-12620), and one driver (all sold separately)
  • Powers a combination of fixtures with a maximum of 15 Watts
  • Operates 1 to 6 LED Under Cabinet Puck Lights (PLT-12600 and PLT-12601; sold separately)
  • Operates 1 to 11 Mini LED Under Cabinet Puck Lights (PLT-12602 and PLT-12603; sold separately)
  • Up to 80% efficiency
  • ETL and IP20 rated for damp locations
  • Integrated J-box for hardwire installation
12V

12V

Dimmable

Dimmable

ETL Listed

ETL Listed

Product Attributes
Brand PLT
Case Quantity 20
Current Type Fixed
Dimmable Yes
Dimming Type Triac
Efficiency up to 80%
Height 1.26 in.
Input Voltage 120
Length 5 in.
Max Output Current 1250mA
Max Output Voltage 12
Maximum Wattage 15 Watt
Minimum Wattage 0.75 Watt
Mounting Hard Wire
Number of Output Channels 1
Operating Temp -13 Deg. to 113 Deg. F
Output Current 1.25 Amps Max
Output Voltage 12 VDC
Ratings and Certifications Damp Location, ETL
Supplier ADISION
Type Constant Voltage
UPC 842821121904
Width 4 in.
Spec Files
    !
