LED AREA LIGHT 300W MAX T3 T5 - 3000-4000-5000K 45000LM MAX - PLT-13145

SKU:
PLT-13145
  • 1000-Watt metal halide equal
  • Type III (pre-installed) and Type V switchable lenses (included)
  • Compatible with PLT shields and mounting accessories (sold separately)
  • 6kV surge protection built-in with additional 10kV surge protection (included)
  • LED L70 life of 145,000 hours
  • Low profile aluminum housing
  • UL rated
  • IP65 rated
  • Up to 150 LPW
  • 0-10V dimmable from the highest wattage selection ONLY
120-277V

120-277V

Dimmable

Dimmable

UL Listed

UL Listed

Product Attributes
Brand PLT
CRI Standard CRI
Case Quantity 1
Color Temperature 3000 Kelvin, 4000 Kelvin, 5000 Kelvin, Selectable CCT
DLC Part Number PLTSNIB212131(1,2,3,4,5,6)
Dimmable Yes
Driver Type Sosen
Family Sabre Series
Finish Bronze
Fixture Type Parking Lot Fixture, Selectable Wattage
Height 3.1 in.
IP Rating IP-65
LED Chip Type Lumileds, SMD 2835
LED L70 Life Hours 145,000
LPW 160
Length 21.5 in.
Light Distribution Type III, Type V
Lumens 31,972, 37,228, 45,922
Metal Halide Equal 1000 Watt
Operating Temp -40 Deg. to 122 Deg. F
Ratings and Certifications UL, Wet Location
Supplier SNCVN
Surge Protection 10kV, 6kV
UPC 842821127999
Voltage 120, 208, 240, 277
Warranty 5-Year Limited
Wattage 200 Watt, 240 Watt, 300 Watt
Weight 11.22
Width 12.7 in.
