LED SLCT WALLPACK 75W PHOTO-EM - 9750LM MAX 2CCT 120-277V - PLT-13676

SKU:
PLT-13676
  • Integrated photocell for dusk-to-dawn operation
  • Heavy-duty die cast aluminum housing
  • Emergency output: 8 Watts (1000 Lumens) for 90 minutes
  • 24-hour recharge time
  • 0-10V dimming
  • Anti-corrosive borosilicate glass lens
  • Manual and self testing features
  • 54,000 LED L70 life hours
  • Excellent efficacy of 140 Lumens Per Watt
  • IP65 Rated
120-277V

120-277V

Dimmable

Dimmable

UL Listed

UL Listed

Product Attributes
Product Brand PLT
Case Quantity 1
Color Temperature 4000 Kelvin / 5000 Kelvin / Selectable CCT
Dimmable Yes
Emergency Operation 90 Minutes
Finish Bronze
Fixture Type Emergency Backup, Selectable Wattage, Wall Pack
Height 9.29 in.
Housing Die Cast Aluminum
IP Rating IP-65
LED Chip Type SMD 2835
LED L70 Life Hours 54,000
LPW 140
Length 14.21 in.
Lens Borosilicate Glass
Lumens 6,975 / 8,400 / 10,500
Metal Halide Equal 250 Watt
Mounting Wall Mount
Operating Temp -40 Deg. to 113 Deg. F
Ratings and Certifications UL, Wet Location
Recharge Time 24 Hours
Sensor Type Photocell
Supplier BESTWON
Surge Protection 6kV
Testing Manual, Self-Testing
Product UPC 842821135413
Voltage 120-277V
Warranty 5-Year Limited
Wattage 45 / 60 / 75
Weight 8.84 lbs
Width 7.28 in.
