Product Attributes
| Product Brand | PLT |
| Case Quantity | 30 |
| Current Type | Adjustable |
| Dimmable | Yes |
| Dimming Type | 0-10 Volt |
| Efficiency | up to 95% |
| Height | 1.32 in. |
| IP Rating | IP-54 |
| Input Voltage | 120, 208, 240, 277 |
| Length | 5.43 in. |
| Life Hours | 50,000 |
| Max Output Current | 5000mA |
| Max Output Voltage | 260 |
| Maximum Wattage | 100 Watt |
| Min Output Current | 300mA |
| Min Output Voltage | 180 |
| Mounting | Side Leads |
| Output Voltage | 180-260 VDC |
| Power Factor | 0.9 |
| Product Type | Constant Current LED Driver |
| Ratings and Certifications | UL |
| Supplier | BESTWON |
| Surge Protection | 6kV |
| Product UPC | 842821130562 |
| Warranty | 5-Year Limited |
| Weight | 0.8 lbs. |
| Width | 2.07 in. |
